Software
Mac Driver (v1.3.3)*
Windows Driver (v1.3.3)*
ORIA iPad Remote
*ORIA V1.3 will automatically install the ORIA Stream Deck Plugin during setup if the Elgato Stream Deck software is already installed on your system.
Minimum system requirements for the ORIA Desktop App:
macOS 10.13.6 High Sierra
Windows 10
More detailed version here
Minimum system requirements for the SoundID Reference software:
macOS 11 Big Sur
Windows 10
Powered by Sonarworks SoundiD Reference*
Supports up to 2.1 Speaker Setups
Ultra low latency Monitoring
Advanced 32-bit AD/DA Converter Technology
Create and Store 4 Custom Calibration Profiles
Switch between Profiles via Hardware
Onboard Room Calibration Processing
EQ, Delay, Trim & Bass Management
1 x Stereo Input (TRS)
1 x Digital Input (S/PDIF)
1 x Stereo Speaker Output (TRS)
1 x Subwoofer Output (TRS)
24 bit / 96kHz
USB 3.0 / USB Type-C
USB Bus Powered
Includes Sonarworks Measurement Mic
MacOS and Windows Compatible
Remote Control
iOS iPad Remote
Stream Deck Support
System Specs
Analogue Input Channels: 2
Analogue Output Channels: 3
Digital Input Channels*: 2
System Sample Rate: 96kHz (with inbuilt sample rate conversion for digital inputs)
*No audio streams over USB. USB is for power and control data only.
Line Output (via Optical Input)
Max Output Level: +18dBu
Dynamic Range (A Weighted): 127dB
THD+N (-1dBFS): -113dB/0.0002%
Frequency Response (20Hz > FS/2*): ± 0.1dB
Crosstalk (1kHz): <-123dB
*FS/2 of the incoming optical signal.
Line Input to Line Output
Max Input Level: +18dBu
Dynamic Range (A Weighted): 122.5dB
THD+N (-1dBFS): -105dB/0.0005%
Frequency Response (20Hz - 40kHz): ± 0.2dB
Crosstalk (1kHz): <-118dB
Digital Input
Stereo S/PDIF: 44.1kHz to 96kHz
USB
Connector Type: USB-C
Bus Power Requirement: 0.9A @ 5V >=USB 3.0 Port
Included Cable: USB-C - 1m
Measurement Mic Specs
Model: MREF Microphone
Microphone Type: Electret-condenser
Transducer Type: MEMS
Frequency Response: 20Hz – 20kHz
Polar Pattern: Omni-directional
Output Impedance: 330O
Sensitivity: -40dBV/Pa
SNR: 65dBA
Dynamic Range: 105dB
Max SPL: 125dBSPL
Power Requirements: +48V Phantom Power
Connector Type: 3 Pin XLR
Weight: 54g
