Features
Half rack chassis capable of receiving up to four transmitters
Each receiver channel can be paired with up to four transmitters, allowing users to instantly switch between different transmitter configurations
Switch between Standard (10 channels) and HD (20 channels) modes
Receiver units can be docked in the chassis or mounted remotely (up to 328 feet away) via Ethernet cable for added versatility
Up to five chassis can be linked and used simultaneously
Monitor transmitter status, audio level, remaining battery time, and other information in A-T Wireless Manager
Auto lock function prevents unintended operations
Specifications
Overall System
Operating Frequencies 2,402 to 2,480 MHz
Dynamic Range 120 dB (A-weighted), typical
Total Harmonic Distortion < 0.05%, typical
Maximum Simultaneous Use (recommended) Standard: 10 channels HD mode: 20 channels
It depends on the region and environment.
System Frequency Response 20 to 20,000 Hz
Varies depending on the microphone to be installed.
